3. Installation and Operation
The packing condition and the external outlook of the unit should be inspected carefully before
installation. Retain the packing material for future use.
3.1 Unpacking
 Take the UPS out of the PE foam.
 Unwrap the UPS.
 Standard Package includes:
 1 set of Quick Start Manual
 1 set of User's Manual
 1 set of UPS communication software with RS232 cable
 1 set of Metal Accessories Kit
 Package for the UPS with Isolation transformer & dual input:
 Ditto, but with additional 3pcs wire No 7.
 Package for the UPS without isolation transformer but dual input:
 Ditto, but with additional 1pcs wire No. 7.
(p.s. Wire No. 7 is to be used at the input/output terminal block of the UPS.
Please refer to Chapter 0 for installation.
With 10KVA model only
With all E6 LCD RT UPS
