Operating & Maintenance Manual Service Tools
118 22442594
Service Tools
Electronic Systems
The following special tools are recommended to perform service procedures in this mannual.
The tools can be purchased from Ingersoll-Rand or equivalent substitutes can be used.
Tool Tool Description
Fluke 87 Digital Multimeter
Used to measure electrical circuits: volts, ohms amps
54729660 Weather-Pack Terminal Removal Tool
Used to repair Packard Electric Weather-Pack Connectors.
54729678 Deutsch Terminal Removal Tool (Blue)
Used to repair Deutsch connectors
54729686 Deutsch Terminal Removal Tool (Red)
Used to repair Deutsch connectors
54729694 Deutsch Terminal Removal Tool (Yellow)
Used to repair Deutsch connectors
HDT-48-00 Deutsch Terminal Crimp Tool
Used to crimp Deutsch connector terminals
DD Deutsch Terminal Crimping Tool
Used to crimp Deutsch connector terminals
54729710 Electrical Contact Cleaner
Used to clean electrical contacts and connectors
54729728 PDA Service Tool
Palm Pilot based service tool used to connect to Intellisys (SGP) Controller
to load software and extract service information
22073886 Packard Crimp Tool
Used to crimp Packard connector terminals
22073878 Thermistor Simulator Plug
Used to test thermistor circuits
54699616 Deutsch Terminal Removal Tool
Used to repair Deutsch connectors
54699657 Deutsch Terminal Removal Tool
Used to repair Deutsch connectors
54749643 Packard Metri-Pack Terminal Removal Tool
Used to repair Metri-Pack connectors
54749635 Connector Repair Kit
Used to make connector repairs
