Camera Setting
Brightness: the luminance of image view. Default value is 8; adjustable from 0 to 16.
Image Setting
Contrast: the ratio of luminance of white to black. Default value is 8; adjustable from 0 to 16.
Saturation: colorfulness of a color related to its own brightness. Default value is 8, adjustable from 0
to 16.
Sharpness: refer to image acutance, which presents in the edges contrast of an image. Default value
is 8, adjustable from 0 to 16.
The 4 correlates are referring image appearance in terms of color/vision that is adjustable according
to user preferences.
Video Orientation: change the image orientation.
• Mirror: rotate the image horizontally.
• Flip: rotate the image vertically.
Note
: These operations are usually applied when camera must be installed in an exceptional
position. For the example of ceiling installation, camera must be installed upside-down.
