LED Indicators
There are 2 type of LED indicators; RJ45 LEDs (back panel) and System LED (front, bicolor). These LEDs
can help to recognize the current device status.
RJ45 LEDs for Network Status:
Bicolor LED indicator for Power & System Status:
Green
Power On / System Reboot Steady ON with Amber LED
Initial Process Ready 3 Flashing then ON with Green LED
Normal Operation Steady ON with Green LED
Firmware Upgrade Flashing per second with Red LED
Internal (Hardware) Failure Steady ON with Red LED
LED1 (Green) LED2 (Amber)
10 Link / Traffic Steady ON / Flashing OFF
100 Link / Traffic Steady ON / Flashing Steady ON
