Section 3: System Installation
3.1 Electrical Requirements
▪ The System will require a separate line supply of single phase (100Vac; 15A) or
(115Vac; 15A) or (230Vac; 15A) or (240Vac; 15A) 50-60Hz.
▪ Power receptacles must be within 15 feet of the System site.
▪ The System should not share a power line with other equipment.
▪ Power receptacle must include protective earth, and must be checked before
connecting the system.
For continued protection against fire, replace the fuse on-ly with one of the
same type and rating.
Proper grounding is essential for safe operation.
3.2 Environmental Requirements
▪ Corrosive materials can damage electronic parts; therefore, the System should
operate in a non-corrosive atmosphere.
▪ For optimal operation of the System, maintain room temperature between 20-27
o
C
(68-79
o
F) and relative humidity of less than 80%.
3.3 Equipment List
The System includes the following:
▪ System platform
▪ Footswitch
▪ Operator manual
▪ Power cord
▪ Handpieces
