E2SS-32R2
14 R e v 1 . 0 T P S , A u g 2 0 23
2.6.5. RAID Level Setting
Refer to Table 12 the position of slide switch J1 J2 for RAID levels configuration.
Table 11: RAID Level setting
J1
J2
RAID 0
2
2
RAID 1
1
2
Port multiplier
1
1
2.6.6. LED Indicator
Refer to Table 13 the LED indicator of status.
Table 12: LED Indicator
Color
Status
RED
Power on
Green
RAID Access
Blue
RAID Error
Green + Blue
RAID Rebuilding
2.7 Packing List
E2SS-32R2 2.5” Card x 1
Screw M2*3.5 Silver x 6
Screw M2*2.5 Black x 4
2.5” SSD Bottom cover x 1
2.5” SSD Top cover x 1
2.8 Software Support
Use native AHCI driver for setting.
