2.6.
Hardware
2.6.1.
Layout
Table 7: PCB La
yout Legen
d
Label
Connector Type
Function
J1 J2
Slid
e Switch SMD 3P 90°
RAID Level setti
ng
J5
DIP 2*5P 90° P:1.27m
m
USB 2.0 Input
I/F
LED access & error fun
cti
on
J6
7+15P 90° MALE H:4
.0mm
SA
T
A
Input I/F
SW1
T
act switch
SMD 4P 180°
RAID Level reset
CON1
CON2
M.
2 SMD 2*67P
mSA
T
A Outpu
t I/F
J6 J5
CON2 CON1
SW1
J2 J1
8
