Innodisk E2SS-32R2 User Manual

E2SS-32R2
3 R e v 1 . 0 T P S , A u g 2 0 23
Product Introduction
1.1. Overview
Innodisk E2SS-32R2 is designed with standard 2.5” form factor, E2SS-32R2 is compatible with
SATAIII(6.0Gb/s) specification, E2SS-32R2 can be configured as 2 ports SATA Hardware striping &
mirror & port multiplier functions, optimized for higher performance and ensure data integrity,
which brings you a flexible expansion solution for embedded systems.
Figure 1: Block Diagram
1.2. Features
 Supports SATA to dual SATA III Port Multiplier
 Supports H/W RAID 0/1 over SATA
 Pin header for Access/Error LED connection
 3 years warranty
 Industrial design, manufacture in innodisk Taiwan
Figure 2: E2SS-32R2 Picture

Innodisk E2SS-32R2 Specifications

General

Brand	Innodisk
Model	E2SS-32R2
Category	Control Unit
Language	English
