Inovance MD280NT3.7GB - Group F2: Input Terminals

Function Code Table MD280 User Manual
- 80 -
Function
Code
Parameter Name Setting Range
Min.
Unit
Default
Property
Group F2: Input Terminals
F2-00
DI1 function
selection
0: No function
)RUZDUG581):'
5HYHUVH5815(9
3: Three-line control
)RUZDUG-2*)-2*
5HYHUVH-2*5-2*
6: Terminal UP
7: Terminal DOWN
8: Coast to stop
)DXOWUHVHW5(6(7
10: RUN pause
1RUPDOO\RSHQ12LQSXW
RIH[WHUQDOIDXOW
1RUPDOO\FORVHG1&
LQSXWRIH[WHUQDOIDXOW
13: Multi-reference terminal 1
14: Multi-reference terminal 2
15: Multi-reference terminal 3
16: Terminal for acceleration/
deceleration time selection
17: UP and DOWN setting
clear
18: DC braking
19: Acceleration/Deceleration
prohibited
20: PID pause
21: PLC status reset
22: Swing pause
23: Counter input
24: Counter reset
25: Length count input
26: Length reset
([FKDQJHRI$,DQG$,
settings
28: Frequency source
switched over to AI1
29: DC braking at stop
enabled
7REHFRQWLQXHG
11
ƾ
F2-01
DI2 function
selection
12
ƾ
F2-02
DI3 function
selection
14
ƾ
