MD380 User Manual Function Code Table
- 125 -
Function
Code
Parameter Name
Setting Range
Default Property
A4-02 Rated motor voltage
1–2000 V
Model
dependent
★
A4-03 Rated motor current
0.01–655.35 A (AC drive power ≤
55 kW)
0.1–6553.5 A (AC drive power >
55 kW)
Model
dependent
★
A4-04 Rated motor frequency
0.01 Hz to maximum frequency
Model
dependent
★
A4-05
Rated motor rotational
speed
1–65535 RPM
Model
dependent
★
A4-06
Stator resistance
(asynchronous motor)
0.001–65.535 Ω (AC drive power
≤ 55 kW)
0.0001–6.5535 Ω (AC drive
power > 55 kW)
Model
dependent
★
A4-07
Rotor resistance
(asynchronous motor)
0.001–65.535 Ω (AC drive power
≤ 55 kW)
0.0001–6.5535 Ω (AC drive
power > 55 kW)
Model
dependent
★
A4-08
Leakage inductive reactance
(asynchronous motor)
0.01–655.35 mH (AC drive power
≤ 55 kW)
0.001–65.535 mH (AC drive
power > 55 kW)
Model
dependent
★
A4-09
Mutual inductive reactance
(asynchronous motor)
0.1–6553.5 mH (AC drive power
≤ 55 kW)
0.01–655.35 mH (AC drive power
> 55 kW)
Model
dependent
★
A4-10
No-load current
(asynchronous motor)
0.01 A to A2-03 (AC drive power
≤ 55 kW)
0.1 A to A2-03 (AC drive power >
55 kW)
Model
dependent
★
A4-16
Stator resistance
(synchronous motor)
0.001–65.535 Ω (AC drive power
≤ 55 kW)
0.0001–6.5535 Ω (AC drive
power > 55 kW)
Model
dependent
★
A4-17
Shaft D inductance
(synchronous motor)
0.01–655.35 mH (AC drive power
≤ 55 kW)
0.001–65.535 mH (AC drive
power > 55 kW)
Model
dependent
★
A4-18
Shaft Q inductance
(synchronous motor)
0.01–655.35 mH (AC drive power
≤ 55 kW)
0.001–65.535 mH (AC drive
power > 55 kW)
Model
dependent
★
