Function Code Table
MD380 User Manual
- 132 -
Function
Code
Parameter Name
Setting Range
Default Property
AC-03 AI1 displayed voltage 2
6.000–9.999 V
Factory
corrected
☆
AC-04 AI2 measured voltage 1
0.500–4.000 V
Factory
corrected
☆
AC-05 AI2 displayed voltage 1
0.500–4.000 V
Factory
corrected
☆
AC-06 AI2 measured voltage 2
6.000–9.999 V
Factory
corrected
☆
AC-07 AI2 displayed voltage 2
9.999–10.000 V
Factory
corrected
☆
AC-08 AI3 measured voltage 1
9.999–10.000 V
Factory
corrected
☆
AC-09 AI3 displayed voltage 1
9.999–10.000 V
Factory
corrected
☆
AC-10 AI3 measured voltage 2
9.999–10.000 V
Factory
corrected
☆
AC-11 AI3 displayed voltage 2
9.999–10.000 V
Factory
corrected
☆
AC-12 AO1 target voltage 1
0.500–4.000 V
Factory
corrected
☆
AC-13 AO1 measured voltage 1
0.500–4.000 V
Factory
corrected
☆
AC-14 AO1 target voltage 2
6.000–9.999 V
Factory
corrected
☆
AC-15 AO1 measured voltage 2
6.000–9.999 V
Factory
corrected
☆
AC-16 AO2 target voltage 1
0.500–4.000 V
Factory
corrected
☆
AC-17 AO2 measured voltage 1
0.500–4.000 V
Factory
corrected
☆
AC-18 AO2 target voltage 2
6.000–9.999 V
Factory
corrected
☆
AC-19 AO2 measured voltage 2
6.000–9.999 V
Factory
corrected
☆
AC-20 AI2 measured current 1 0.000–20.000 mA
Factory
corrected
☆
AC-21 AI2 sampling current 1 0.000–20.000 mA
Factory
corrected
☆
AC-22 AI2 measured current 2 0.000–20.000 mA
Factory
corrected
☆
AC-23 AI2 sampling current 2 0.000–20.000 mA
Factory
corrected
☆
