Function Code Table
MD380 User Manual
- 134 -
Function Code Parameter Name Min. Unit
Communication
Address
Group U0: Standard Monitoring Parameters
U0-23 AI3 voltage before correction 0.001 V 7017H
U0-24 Linear speed 1 m/Min 7018H
U0-25 Accumulative power-on time 1 Min 7019
U0-26 Accumulative running time 0.1 Min 701AH
U0-27 Pulse input frequency 1 Hz 701BH
U0-28 Communication setting value 0.01% 701CH
U0-29 Encoder feedback speed 0.01 Hz 701DH
U0-30 Main frequency X 0.01 Hz 701EH
U0-31 Auxiliary frequency Y 0.01 Hz 701FH
U0-32 Viewing any register address value 1 7020H
U0-33 Synchronous motor rotor position 0.1
°
7021H
U0-34
Motor temperature 1°C
7022H
U0-35 Target torque 0.1% 7023H
U0-36 Resolver position 1 7024H
U0-37 Power factor angle
0.1°
7025H
U0-38 ABZ position 1 7026H
U0-39 Target voltage upon V/F separation 1 V 7027H
U0-40 Output voltage upon V/F separation 1V 7028H
U0-41 DI state visual display 1 7029H
U0-42 DO state visual display 1 702AH
U0-43 DI function state visual display 1 1 702BH
U0-44 DI function state visual display 2 1 702CH
U0-45 Fault information 1 702DH
U0-58 Phase Z counting 1 703AH
U0-59 Current set frequency 0.01% 703BH
U0-60 Current running frequency 0.01% 703CH
U0-61 AC drive running state 1 703DH
U0-62 Current fault code 1 703EH
U0-63
Sent value of point-point
communication
0.01% 703FH
U0-64
Received value of point-point
communication
0.01% 7040H
U0-65 Torque upper limit 0.1% 7041H
