Description of Function Codes
MD380 User Manual
- 174 -
Value Function Description
19
Undervoltage state
output
If the AC drive is in undervoltage state, the terminal
becomes ON.
20
Communication
setting
Refer to the communication protocol.
21 Reserved Reserved.
22 Reserved Reserved.
23
Zero-speed running 2
(having output at stop)
If the output frequency of the AC drive is 0, the terminal
becomes ON. In the state of stop, the signal is still ON.
24
Accumulative power-
on time reached
If the AC drive accumulative power-on time (F7-13)
exceeds the value set in F8-16, the terminal becomes ON.
25
Frequency level
detection FDT2 output
Refer to the descriptions of F8-28 and F8-29.
26 Frequency 1 reached Refer to the descriptions of F8-30 and F8-31.
27 Frequency 2 reached Refer to the descriptions of F8-32 and F8-33.
28 Current 1 reached Refer to the descriptions of F8-38 and F8-39.
29 Current 2 reached Refer to the descriptions of F8-40 and F8-41.
30 Timing reached
If the timing function (F8-42) is valid, the terminal becomes
ON after the current running time of the AC drive reaches
the set time.
31
AI1 input limit
exceeded
If AI1 input is larger than the value of F8-46 (AI1 input
voltage upper limit) or lower than the value of F8-45 (AI1
input voltage lower limit), the terminal becomes ON.
32 Load becoming 0 If the load becomes 0, the terminal becomes ON.
33 Reverse running
If the AC drive is in the reverse running state, the terminal
becomes ON.
34 Zero current state Refer to the descriptions of F8-28 and F8-29.
35
IGBT temperature
reached
If the heatsink temperature of the AC drive IGBT (F7-07)
reaches the set IGBT temperature threshold (F8-47), the
terminal becomes ON.
36
Software current limit
exceeded
Refer to the descriptions of F8-36 and F8-37.
37
Frequency lower
limit reached (having
output at stop)
If the running frequency reaches the lower limit, the terminal
becomes ON. In the stop state, the signal is still ON.
38 Alarm output
If a fault occurs on the AC drive and the AC drive continues
to run, the terminal outputs the alarm signal.
39
Motor overheat
warning
If the motor temperature reaches the temperature set in
F9-58 (Motor overheat warning threshold), the terminal
becomes ON. You can view the motor temperature by using
U0-34.
40
Current running time
reached
If the current running time of AC drive exceeds the value of
F8-53, the terminal becomes ON.
