Function Code Parameter Name Setting Range Default
F5-10 AO1 offset coefcient -100.0%–100.0% 0.0%
F5-11 AO1 gain -10.00–10.00 1.00
F5-12 AO2 offset coefcient -100.0%–100.0% 0.00%
F5-13 AO2 gain -10.00–10.00 1.00
These parameters are used to correct the zero drift of analog output and the output
amplitude deviation. They can also be used to dene the desired AO curve.
If "b" represents zero offset, "k" represents gain, "Y" represents actual output, and "X"
represents standard output, the actual output is: Y = kX + b.
The zero offset coefficient 100% of AO1 and AO2 corresponds to 10 V (or 20 mA). The
standard output refers to the value corresponding to the analog output of 0 to 10 V (or 0 to
20 mA) with no zero offset or gain adjustment.
For example, if the analog output is used as the running frequency, and it is expected that
the output is 8 V when the frequency is 0 and 3 V at the maximum frequency, the gain shall
be set to -0.50, and the zero offset shall be set to 80%.
Function Code Parameter Name Setting Range Default
F5-17 FMR output delay time
0.0–3600.0s 0.0s
F5-18 Relay 1 output delay time
0.0–3600.0s 0.0s
F5-19 Relay 2 output delay time
0.0–3600.0s 0.0s
F5-20 DO1 output delay time
0.0–3600.0s 0.0s
F5-21 DO2 output delay time
0.0–3600.0s 0.0s
These parameters are used to set the delay time of output terminals FMR, relay 1, relay 2,
DO1 and DO2 from status change to actual output.
Function Code Parameter Name Setting Range Default
F5-22
DO valid mode
selection
Unit's digit (FMR valid mode)
00000
0: Positive logic
1: Negative logic
Ten's digit (Relay 1 valid mode)
0, 1 (same as FMR)
Hundred's digit (Relay 2 valid mode)
0, 1 (same as FMR)
Thousand's digit (DO1 valid mode)
0, 1 (same as FMR)
Ten thousand's digit (DO2 valid mode)
0, 1 (same as FMR)
