MD380 User Manual Desc
ription of Function Codes
- 221 -
Function Code Parameter Name Setting Range Default
FP-02
AC drive
parameter display
property
Unit's digit (Group U display selection)
11
0: Not display
1: Display
Ten's digit (Group A display selection)
0: Not display
1: Display
FP-03
Individualized
parameter display
property
Unit's digit (User-dened parameter
display selection)
00
0: Not display
1: Display
Ten's digit (User-modied parameter
display selection)
0: Not display
1: Display
The setting of parameter display mode aims to facilitate you to view different types of
parameters based on actual requirements. The MD380 provides the following three
parameter display modes.
Table 6-9 Three parameter display modes provided by MD380
Name Description
AC drive parameter display Display function codes of the AC drive in sequence of F0
to FF, A0 to AF and U0 to UF.
User-dened parameter display Display a maximum of 32 user-dened parameters
included in group FE.
User-modied parameter display Display the parameters that are modied.
If one digit of FP-03 is set to 1, you can switch over to different parameter display modes by
pressing key
QUICK
. By default, the AC drive parameter display mode is used.
The display codes of different parameter types are shown in the following table.
Table 6-10 Display codes of different parameter types
Parameter Type Display Code
AC drive parameter
User-dened parameter
User-modied parameter
