MD380 User Manual EMC
- 251 -
AC Drive Model
Power
Capacity
(kVA)
Rated
Input
Current
(A)
AC Input Filter Model
(Changzhou Jianli)
AC Input Filter Model
(Schaffner)
MD380-5T110G 160 214 DL-250EBK5 FN 3270H-250-99
MD380-5T132G 192 256 DL-300EBK3 FN 3270H-320-99
MD380-5T160G 231 307 DL-400EBK3 FN 3270H-320-99
MD380-5T200G 250 385 DL-400EBK3 FN 3270H-400-99
MD380-5T220G 280 430 DL-600EBK3 FN 3270H-600-99
MD380-5T250G 355 468 DL-600EBK3 FN 3270H-600-99
MD380-5T280G 396 525 DL-600EBK3 FN 3270H-600-99
MD380-5T315G 445 590 DL-600EBK3 FN 3270H-600-99
MD380-5T355G 500 665 DL-700EBK3 FN 3270H-800-99
MD380-5T400G 565 785 DL-800EBK3 FN 3270H-800-99
Three-phase 690 V, 50/60 Hz
MD380-7T55G 84 70 DL-100EBK5-CHV -
MD380-7T75G 107 90 DL-100EBK5-CHV -
MD380-7T90G 125 105 DL-130EBK51-CHV -
MD380-7T110G 155 130 DL-160EBK5-CHV -
MD380-7T132G 192 170 DL-200EBK5-CHV -
MD380-7T160G 231 200 DL-250EBK31/60 -
MD380-7T200G 250 235 DL-250EBK31/60 -
MD380-7T220G 280 247 DL-250EBK31/60 -
MD380-7T250G 355 265 No recommendation -
MD380-7T280G 396 305 No recommendation -
MD380-7T315G 445 350 No recommendation -
MD380-7T355G 500 382 No recommendation -
MD380-7T400G 565 435 DL-600EBK35/60 -
MD380-7T450G 630 490 DL-600EBK35/60 -
MD380-7T500G 700 595 DL-600EBK35/60 -
7.3.2 Installation of AC Input Reactor on Power Input Side
An AC input reactor is installed to eliminate the harmonics of the input current. As an optional
device, the reactor can be installed externally to meet strict requirements of an application
environment for harmonics. The following table lists the recommended manufacturers and
models of input reactors.
Table 7-2 Recommended manufacturers and models of AC input reactors
AC Drive Model
Rated Input Current
(A)
AC Input Reactor Model
(Inovance)
Three-phase power: 380 V, 50/60 Hz
MD380T0.7GB 3.4 MD-ACL-7-4T-222-2%
MD380T1.5GB 5 MD-ACL-7-4T-222-2%
