EMC
MD380 User Manual
- 254 -
Table 7-3 Cable length threshold when an AC output reactor is installed
AC Drive Power
(kW)
Rated Voltage
(V)
Cable Length Threshold
(m)
4 200–500 50
5.5 200–500 70
7.5 200–500 100
11 200–500 110
15 200–500 125
18.5 200–500 135
22 200–500 150
≥ 30 280–690 150
The following table lists the recommended manufacturer and models of AC output reactors.
Table 7-4 Recommended manufacturer and models of AC output reactors
AC Drive Model
Rated Output Current
(A)
AC Output Reactor Model
(Shanghai Eagtop)
Three-phase 380 V, 50/60 Hz
MD380T0.7GB 2.1 OCL-0005-EISC-E1M4
MD380T1.5GB 3.8 OCL-0005-EISC-E1M4
MD380T2.2GB 5.1 OCL-0007-EISC-E1M0
MD380T3.7GB 9 OCL-0010-EISC-EM70
MD380T5.5GB
MD380T7.5GB
MD380T11GB
13 OCL-0015-EISC-EM47
17 OCL-0020-EISC-EM35
25 OCL-0030-EISC-EM23
MD380T15GB 32 OCL-0040-EISC-EM18
MD380T18.5G 37 OCL-0050-EISC-EM14
MD380T22G 45 OCL-0060-EISC-EM12
MD380T30G 60 OCL-0080-EISC-E87U
MD380T37G 75 OCL-0090-EISC-E78U
MD380T45G 91 OCL-0120-EISC-E58U
MD380T55G 112 OCL-0150-EISH-E47U
MD380T75G 150 OCL-0200-EISH-E35U
MD380T90G 176 OCL-0200-EISH-E35U
MD380T110G 210 OCL-0250-EISH-E28U
MD380T132G 253 OCL-0290-EISH-E24U
MD380T160G 304 OCL-0330-EISH-E21U
MD380T200G 377 OCL-0490-EISH-E14U
MD380T220G 426 OCL-0490-EISH-E14U
MD380T250G 465 OCL-0530-EISH-E13U
MD380T280G 520 OCL-0600-EISH-E12U
MD380T315G 585 OCL-0660-EISH-E4U0
MD380T355G 650 OCL-0800-EISH-E5U0
