MD380 User Manual Selection and Dimensions
- 277 -
AC Drive Model
MCCB
(A)
Contactor
(A)
Cable of Input
Side Main Circuit
(mm
2
)
Cable of Output
Side Main Circuit
(mm
2
)
Cable of Control
Circuit
(mm
2
)
MD380T30G 100 65 16 16 1.0
MD380T37G 100 80 25 25 1.0
MD380T45G 125 95 35 35 1.0
MD380T55G 160 115 50 50 1.0
MD380T75G 225 170 70 70 1.0
MD380T90G 250 205 95 95 1.0
MD380T110G 315 245 120 120 1.0
MD380T132G 350 300 120 120 1.0
MD380T160G 400 300 150 150 1.0
MD380T200G 500 410 185 185 1.0
MD380T220G 630 475 240 240 1.0
MD380T250G 630 475 120 x 2 120 x 2 1.0
MD380T280G 700 620 120 x 2 120 x 2 1.0
MD380T315G 800 620 150 x 2 150 x 2 1.0
MD380T355G 1000 800 185 x 2 185 x 2 1.0
MD380T400G 1250 800 240 x 2 240 x 2 1.0
Three-phase 480 V
MD380-5T0.7GB 6 9 0.75 0.75 0.5
MD380-5T1.5GB 10 9 0.75 0.75 0.5
MD380-5T2.2GB 10 9 0.75 0.75 0.5
MD380-5T3.7GB 16 12 1.5 1.5 0.5
MD380-5T5.5GB 20 18 2.5 2.5 0.75
MD380-5T7.5GB 32 25 4.0 4.0 0.75
MD380-5T11GB 40 32 4.0 4.0 0.75
MD380-5T15GB 50 38 6.0 6.0 0.75
MD380-5T18.5G 50 40 10 10 1.0
MD380-5T22G 63 50 10 10 1.0
MD380-5T30G 100 65 16 16 1.0
MD380-5T37G 100 80 25 25 1.0
MD380-5T45G 125 95 35 35 1.0
MD380-5T55G 160 115 50 50 1.0
MD380-5T75G 225 170 70 70 1.0
MD380-5T90G 250 205 95 95 1.0
MD380-5T110G 315 245 120 120 1.0
MD380-5T132G 350 300 120 120 1.0
MD380-5T160G 400 300 150 150 1.0
