MD380 User Manual Operation, Display and Application Example
- 51 -
FP-03 is used to determine whether the user-dened group and user-modied group are
displayed.
Function Code Name Setting Range Default
FP-03
Whether user-dened
group and user-
modied group are
displayed
Unit's digit:
-USEr
group display selection
11
0: Not display
1: Display
Ten's digit:
--C--
group display selection
0: Not display
1: Display
-bASE
It indicates all function codes of the MD380. After the mode is switched over to
-bASE
,
level I menu is displayed.
-USEr
The user-dened menu is set to facilitate viewing and modifying of commonly used function
codes. In this mode, the display parameter uF3.02 indicates function code F3-02. You can
also modify parameters in this mode as in common editing state. After the mode is switched
over to
-USEr
, level II menu is displayed.
The user-dened parameters are included in group FE. If FE is set to F0.00, it indicates that
no function codes are available. A maximum of 30 parameters can be included in group FE.
If "NULL" is displayed, it indicates that the user-dened menu is null.
A total of 16 parameters are pre-stored in the user-dened menu, as listed in the following
table.
F0-01 Motor 1 control mode F3-01 Torque boost
F0-02 Command source selection F4-00 DI1 function selection
F0-03 Main frequency source X selection F4-01 DI2 function selection
F0-07 Frequency source selection F4-02 DI3 function selection
F0-08 Preset frequency F5-04 DO1 function
F0-17 Acceleration time 1 F5-07 AO1 function selection
F0-18 Deceleration time 1 F6-00 Start mode
F3-00 V/F curve setting F6-10 Stop mode
You can edit the user-dened menu based on actual requirements.
--C--
In you modified menu, only the parameters that are modified to a non-default value are
displayed. The menu is generated by the AC drive automatically. After the mode is switched
over to
--C--
, level II menu is displayed.
