Inovance MD380 Series

MD380 User Manual Desc
ription of Function Codes
- 173 -
Function Code Parameter Name Setting Range Default
F4-38
DI valid mode
selection 1
8QLWVGLJLW',YDOLGPRGH
00000
0: High level valid
1: Low level valid
Ten's digit (DI2 valid mode)
Same as DI1
Hundred's digit (DI3 valid mode)
Same as DI1
Thousand's digit (DI4 valid mode)
Same as DI1
Ten thousand's digit (DI5 valid mode)
Same as DI1
F4-39
DI valid mode
selection 2
8QLWVGLJLW',YDOLGPRGH
00000
Same as DI1
Ten's digit (DI7 valid mode)
Same as DI1
Hundred's digit (DI8 state)
Same as DI1
Thousand's digit (DI9 valid mode)
Same as DI1
Ten thousand's digit (DI10 valid
mode)
0, 1 (same as DI1)
These parameters are used to set the valid mode of DI terminals.
 0: High level valid
7KH',WHUPLQDOLVYDOLGZKHQEHLQJFRQQHFWHGZLWK&20DQGLQYDOLGZKHQEHLQJ
GLVFRQQHFWHGIURP&20
 1: Low level valid
7KH',WHUPLQDOLVLQYDOLGZKHQEHLQJFRQQHFWHGZLWK&20DQGLQYDOLGZKHQEHLQJ
GLVFRQQHFWHGIURP&20
Function Code Parameter Name Setting Range Default
F4-40 AI2 input signal selection
0: Voltage signal
1: Current signal
0
AI2 supports voltage/current output, which is determined by jumper. After setting the jumper,
perform corresponding setting in F4-40.
