Inovance MD380 Series

MD380 User Manual Desc
ription of Function Codes
- 177 -
Table 6-6 Relationship between pulse and analog output ranges and corresponding
functions
Value Function
Range (Corresponding to Pulse or Analog
2XWSXW5DQJH±
0 Running frequency 0 to maximum frequency
1 Frequency reference 0 to maximum frequency
2 2XWSXWFXUUHQW 0 to 2 times of rated motor current
3 2XWSXWWRUTXHDEVROXWHYDOXH 0 to 2 times of rated motor torque
4 2XWSXWSRZHU 0 to 2 times of rated power
5 2XWSXWYROWDJH 0 to 1.2 times of rated AC drive voltage
6 Pulse input 0.01–100.00 kHz
7 AI1 0–10 V
8 AI2 0–10 V (or 0–20 mA)
9 AI3 0–0 V
10 Length 0 to maximum set length
11 Count value 0 to maximum count value
12 Communication reference 0.0%–100.0%
13 Motor speed
0 to rotational speed corresponding to
maximum output frequency
14 2XWSXWFXUUHQW 0.0–1000.0 A
15 2XWSXWYROWDJH 0.0–000.0 V
16 2XWSXWWRUTXHDFWXDOYDOXH
-2 times of rated motor torque to 2 times of
rated motor torque
Function Code Parameter Name Setting Range Default
F5-09 Maximum FMP output frequency 0.01–100.00 kHz 50.00 kHz
If the FM terminal is used for pulse output, this parameter is used to set the maximum
frequency of pulse output.
Function Code Parameter Name Setting Range Default
F5-10 $2]HURRIIVHWFRHI¿FLHQW -100.0% to 100.0% 0.0%
F5-11 $2JDLQ -10.00 to 10.00 1.00
F5-12 $2]HURRIIVHWFRHI¿FLHQW -100.0% to 100.0% 0.00%
F5-13 $2JDLQ -10.00 to 10.00 1.00
These parameters are used to correct the zero offset of analog output and the output
DPSOLWXGHGHYLDWLRQ7KH\FDQDOVREHXVHGWRGH¿QHWKHGHVLUHG$2FXUYH
