Inovance MD380 Series

Description of Function Codes
MD380 User Manual
- 176 -
Value Function Description
30 Timing reached
If the timing function (F8-42) is valid, the terminal becomes
21DIWHUWKHFXUUHQWUXQQLQJWLPHRIWKH$&GULYHUHDFKHV
the set time.
31
AI1 input limit
exceeded
If AI1 input is larger than the value of F8-46 (AI1 input
voltage upper limit) or lower than the value of F8-45 (AI1
LQSXWYROWDJHORZHUOLPLWWKHWHUPLQDOEHFRPHV21
32 Load lost ,IWKHORDGEHFRPHVWKHWHUPLQDOEHFRPHV21
33 Reverse running
If the AC drive is in the reverse running state, the terminal
EHFRPHV21
34 Zero current state Refer to the descriptions of F8-28 and F8-29.
35
Module temperature
reached
If the heatsink temperature of the inverter module (F7-07)
reaches the set module temperature threshold (F8-47), the
WHUPLQDOEHFRPHV21
36
2XWSXWFXUUHQWOLPLW
exceeded
Refer to the descriptions of F8-36 and F8-37.
37
Frequency lower
limit reached (having
output at stop)
If the running frequency reaches the lower limit, the terminal
EHFRPHV21,QWKHVWRSVWDWHWKHVLJQDOLVVWLOO21
38 Alarm output
If a fault occurs on the AC drive and the AC drive continues
to run, the terminal outputs the alarm signal.
39
Motor overheat
pending
If the motor temperature reaches the temperature set in
F9-58 (Motor overheat pending threshold), the terminal
EHFRPHV21<RXFDQYLHZWKHPRWRUWHPSHUDWXUHE\XVLQJ
8
40
Current running time
reached
If the current running time of AC drive exceeds the value of
)WKHWHUPLQDOEHFRPHV21
Function Code Parameter Name Default
F5-06 FMP function selection 0
F5-07 $2IXQFWLRQVHOHFWLRQ 0
F5-08 $2IXQFWLRQVHOHFWLRQ 1
The output pulse frequency of the FMP terminal ranges from 0.01 kHz to "Maximum FMP
output frequency" (F5-09). The value of F5-09 is between 0.01 kHz and 100.00 kHz.
7KHRXWSXWUDQJHRI$2DQG$2LV±9RU±P$7KHUHODWLRQVKLSEHWZHHQSXOVH
and analog output ranges and corresponding functions is listed in the following table.
