Inovance MD380 Series

MD380 User Manual Desc
ription of Function Codes
- 181 -
'&LQMHFWLRQEUDNLQJLVYDOLGRQO\IRUGLUHFWVWDUWXS) ,QWKLVFDVHWKH$&GULYH
performs DC injection braking at the DC injection braking 1 level. After DC injection braking
1 level, the AC drive starts to run. If the DC injection braking 1 level is 0, the AC drive starts
directly without DC injection braking. The larger the DC injection braking 1 level is, the larger
the braking force is.
,IWKHVWDUWXSPRGHLVSUHH[FLWHGVWDUWXS) WKH$&GULYHEXLOGVPDJQHWLFILHOG
based on the set pre-excited current. After the pre-excited time, the AC drive starts to run. If
the pre-excited time is 0, the AC drive starts directly without pre-excitation.
The DC injection braking 1 level or pre-excitation level current is a percentage relative to the
base value.
 If the rated motor current is less than or equal to 80% of the rated AC drive current, the
base value is the rated motor current.
 If the rated motor current is greater than 80% of the rated AC drive current, the base
value is 80% of the rated AC drive current.
Function Code Parameter Name Setting Range Default
F6-07
Acceleration/
Deceleration mode
0: Linear acceleration/deceleration
1: S-curve acceleration/deceleration A
0
It is used to set the frequency change mode during the AC drive start and stop process.
 0: Linear acceleration/deceleration
The output frequency increases or decreases in linear mode. The MD380 provides four
group of acceleration/deceleration time, which can be selected by using F4-00 to F4-08.
 1: S-curve acceleration/deceleration A
The output frequency increases or decreases along the S curve. This mode is generally
used in the applications where start and stop processes are relatively smooth, such as
HOHYDWRUDQGFRQYH\RUEHOW)DQG)UHVSHFWLYHO\GH¿QHWKHWLPHSURSRUWLRQVRI
the start segment and the end segment.
:KHQWKHIUHTXHQF\UHIHUHQFHLVKLJKHUWKDQWKHUDWHGIUHTXHQF\WKHDFFHOHUDWLRQ
deceleration time is:
2
5
9
b
f
T
f
t
4
(
u(
)

9
)u
In the formula,
f
is the frequency reference,
b
f
is the rated motor frequency and
T
is the acceleration time from 0 Hz to
b
f
.
