Inovance MD380 Series - Page 245

MD380 User Manual Desc
ription of Function Codes
- 245 -
Function Code Parameter Name Display Range
8 Feedback speed
-320.00–320.00 Hz
-500.0–500.0 Hz
It displays the actual output frequency of the AC drive.
The ten’s digit of F7-12 (Number of decimal places for load speed display) determines the
QXPEHURIGHFLPDOSODFHVRI88 
 If the ten’s digit is set to 2, the display range is -320.00–320.00 Hz.
 If the ten’s digit is set to 1, the display range is -500.0 Hz–500.0 Hz.
Function Code Parameter Name Display Range
8 Remaining running time 0.0–6500.0 min
It displays the remaining running time when the timing operation is enabled. For details on
timing operation, refer to F8-42 to F8-44.
Function Code Parameter Name Display Range
8 AI1 voltage before correction 0.00–10.57 V
8 AI2 voltage (V)/ current (mA) before correction
0.00–10.57 V
0.00–20.00 mA
8 AI3 voltage before correction -10.57–10.57 V
They display the AI sampleding voltage/current value of AI. The actually used voltage/
current is obtained after linear correction to reduce the deviation between the sampled
voltage/current and the actual input voltage/current.
)RUDFWXDOFRUUHFWHGYROWDJHVHH88DQG85HIHUWRJURXS$&IRU WKH
correction mode.
Function Code Parameter Name Display Range
8 Linear speed 0–65535 m/min
It displays the linear speed of the DI5 high-speed pulse sampling. The unit is meter/minute.
The linear speed is obtained according to the actual number of pulses sampled per minute
and FB-07 (Number of pulses per meter).
Function Code Parameter Name Display Range
8 Pulse input frequency 0–65535 Hz
It displays the DI5 high-speed pulse sampling frequency, in minimum unit of 1 Hz. It is the
VDPHDV8H[FHSWIRUWKHGLIIHUHQFHLQXQLWV
Function Code Parameter Name Display Range
8 Communication setting value -100.00%–100.00%
It displays the data written by means of the communication address 0x1000.
