Inovance MD380 Series

Description of Function Codes
MD380 User Manual
- 246 -
Function Code Parameter Name Display Range
8 Encoder feedback speed
-320.00–320.00 Hz
-500.0–500.0 Hz
It displays the motor running frequency measured by the encoder.
The ten’s digit of F7-12 (Number of decimal places for load speed display) determines the
QXPEHURIGHFLPDOSODFHVRI88 
 If the ten’s digit is set to 2, the display range is -320.00–320.00 Hz.
 If the ten’s digit is set to 1, the display range is -500.0 Hz–500.0 Hz.
Function Code Name Display Range
8 Main frequency X 0.00–500.00 Hz
It displays the setting of main frequency X.
Function Code Parameter Name Display Range
8 Auxiliary frequency Y 0.00–500.00 Hz
It displays the setting of auxiliary frequency Y.
Function Code Parameter Name Display Range
8 Motor temperature 0–20
0 °C
It displays the motor temperature obtained by means of AI3 sampling. For the motor
temperature detection, see F9-56.
Function Code Parameter Name Display Range
8 Target torque -200.0%–200.0%
It displays the current torque upper limit.
Function Code Parameter Name Display Range
8 Resolver position 0–4095
It displays the current resolver position.
Function Code Parameter Name Display Range
8 Power factor angle -
It displays the current power factor angle.
Function Code Parameter Name Display Range
8 ABZ position 0–65535
,WGLVSOD\VWKHSKDVH$DQG%SXOVHFRXQWLQJRIWKHFXUUHQW$%=RU89:HQFRGHU7KLVYDOXH
is four times the number of pulses that the encoder runs. For example, if the display is 4000,
WKHDFWXDOQXPEHURISXOVHVWKDWWKHHQFRGHUUXQVLV 
