Inovance MD380 Series

Operation, Display and Application Examples MD380 User Manual
- 80 -
8VHRI([WHQVLRQ,QWHUIDFHV
The extension card and functions are described in the following table.
Table 4-4 Extension cards and functions
Name Model Function Remark
,2H[WHQVLRQ
card 1
0',2
,WH[WHQGV¿YH',VDQDQDORJYROWDJH
input AI3 (isolation analog) connected
to PT100, PT1000, a relay output, a
'2DQGDQ$2,WVXSSRUWV56DQG
CAN protocols.
Applied to the models
RIN:DQGDERYH
,2H[WHQVLRQ
card 2-Size B
0',2 It extends three DI terminals. Applied to all models.
Modbus
communication
card
MD32-232
RS232 communication terminal without
isolation, compatible with RJ45
Applied to all models.
MD38TX1
RS485 communication card with
isolation
Applied to all models.
CANlink
communication
extension card
MD38CAN1 CANlink communication adapter Applied to all models.
CANopen
communication
extension card
MD38CAN2 CANopen communication adapter Applied to all models.
3UR¿EXV'3
communication
card
MD38DP 3UR¿EXV'3FRPPXQLFDWLRQDGDSWHU
Applied to the models
RIN:DQGDERYH
8VHU
programmable
card
MD38PC1
8VHUSURJUDPPDEOHH[WHQVLRQFDUG
completely compatible with Inovance's
+8VHULHV3/&
Applied to the models
RIN:DQGDERYH
Differential
encoder
interface card
MD38PG1
Differential rotating encoder interface
card, requiring 5 V power supply
Applied to all models.
Resolver
interface card
MD38PG4
Applied to resolver, excitation
frequency 10 kHz, DB9 interface
Applied to all models.
2SHQFROOHFWRU
encoder card
MD38PG5
2SHQFROOHFWRUHQFRGHULQWHUIDFHFDUG
requiring 15 V power supply
Applied to all models.
