MD380 User Manual Function Code Table
- 95 -
Function
Code
Parameter Name
Setting Range
Default Property
F4-05 DI6 function selection
30: Pulse input (valid only for DI5)
31:Reserved
32: Immediate DC injection
braking
33: External fault NC input
)UHTXHQF\PRGL¿FDWLRQ
enabled
35: PID action direction reverse
0 ƾ
F4-06 DI7 function selection
36: External stop terminal 1
37: Command source switchover
terminal 2
38: PID integral disabled
39: Switchover between main
frequency source X and preset
frequency
0 ƾ
F4-07 DI8 function selection
40: Switchover between auxiliary
frequency source Y and preset
frequency
41: Motor selection terminal
42: Reserved
43: PID parameter switchover
0 ƾ
F4-08 DI9 function selection
8VHUGH¿QHGIDXOW
8VHUGH¿QHGIDXOW
46: Speed control/Torque control
47: Emergency stop
0 ƾ
F4-09 DI10 function selection
48: External stop terminal 2
49: Deceleration DC injection
braking
50: Clear the current running time
51: Switchover between two-
wire control mode and three-wire
control mode
52: REV prohibited
53–59: Reserved
0 ƾ
F4-10 ',¿OWHUWLPH
0.000–1.000s
0.010s ƿ
F4-11 Terminal command mode
0: Two-wire control mode 1
1: Two-wire control mode 2
2: Three-wire control mode 1
3: Three-wire control mode 2
0 ƾ
F4-12 7HUPLQDO83'2:1UDWH
0.001–65.535 Hz/s
1.00 Hz/s ƿ
F4-13 AI curve 1 minimum input
0.00 V to F4-15
0.00 V ƿ
