3 Peripheral Devices and Options
-
97
-
Controller Model
Power Capacity
(kVA)
Rated Input
Current (A)
Simple EMC Input Filter
Model
(Changzhou Jianli)
NICE-L-C-4037
57.0 77.0 DL-120EBK5
NICE-L-C-4037F
NICE-L-C-4045
69.0 93.0 DL-120EBK5
NICE-L-C-4045F
NICE-L-C-4055
85.0 113.0 DL-120EB1/10
NICE-L-C-4055F
NICE-L-C-4075
114.0 157.5 DL-180EB1/10
NICE-L-C-4075F
NICE-L-C-4090 134.0 180.0 DL-180EB1/10
NICE-L-C-4110 160.0 214.0 None
NICE-L-C-4132 192.0 256.0 None
NICE-L-C-4160 231.0 307.0 None

NICE-L-C-2002 4.0 11.0 DL-15EB1/10
NICE-L-C-2003 5.9 17.0 DL-35EB1/10
220-NICE-L-C-4007 7.0 20.5 DL-35EB1/10
220-NICE-L-C-4011 10.0 29.0 DL-35EB1/10
220-NICE-L-C-4015 12.6 36.0 DL-65EB1/10
220-NICE-L-C-4018
15.0 41.0 DL-65EB1/10
220-NICE-L-C-4018F
220-NICE-L-C-4022
18.3 49.0 DL-65EB1/10
220-NICE-L-C-4022F
220-NICE-L-C-4030
23.0 62.0 DL-65EB1/10
220-NICE-L-C-4030F
3.2.4 Selection Guide of Braking Components
1 Regen esistor
Selection of resistance of of regen. resistor
During braking, almost all regenerative energy of the motor is consumed by the regen.
resistor. The resistance of the regen. resistor is calculated by the following formula:
U × U/R = Pb
󶍽
The MD500 AC drive usually selects the 760 V braking voltage, which can be adjusted
by setting F9-08;

Selection of power of regen. resistor
In theory, power of regen. resistor is the same as the braking power. However,
consideration must be given to the deration K. The following formula shall be used:
K × Pr = Pb × D
