Inovance WL432-DB User Manual

‑11‑
■ Mounting on a DIN rail
2
3
1
A
B
1. Pull down the DIN rail mounting hook at the back of the module.
2. Hook the upper fixing jaw on the module to the top edge of the DIN tail along
direction A, and press the module along direction B, until the module is completely
embedded in the DIN rail.
3. Push up the DIN rail mounting hook until you hear a click. If the DIN rail mounting
hook is out of the reach of your fingers, use a tool, such as a screwdriver.
● Keep metal objects away from the top and sides of the antenna.
● Do not put the antenna in a shielded place, such as a metal cabinet.
● Keep the antenna and its feed away from the power and signal cables to
avoid mutual interference.
