6
NS-24E40SNA14 Insignia 24" LED TV
www.insigniaproducts.com
Installing a wall-mount bracket
To attach your TV to a wall-mount bracket:
1 Carefully place your TV face-down on a cushioned, clean surface to protect the screen from damages and
scratches.
2 Attach the wall-mount bracket to your TV using the mounting holes on the back of your TV. See the instructions
that came with the wall-mount bracket for information about how to correctly hang your TV.
Warning
This TV is intended to be supported by a UL Listed wall mount bracket with
suitable weight/load. (See “Miscellaneous” on page 72.)
Notes
• The length of the wall-mount screws vary depending on the wall-mount
bracket you purchased. See the instructions that came with the
wall-mount bracket for screw lengths.
• The mounting holes on the back of your TV take type M4 screws.
3.94 in. (100 mm)
3.94 in. (100 mm)
