11
Insignia 4.3 Cubic Foot Compact Refrigerator
www.insigniaproducts.com
Reversing the door position
You will need: A 10 mm socket driver and a Phillips screw driver available.
• Make sure that your refrigerator is unplugged and empty.
• Have someone available to assist you in the process.
• Keep all of the parts you remove to reuse them later.
• Removing the door requires that the refrigerator be tilted backwards. Rest
the refrigerator on something solid, such as a chair, just below the top
panel.
• Do not lay the refrigerator completely flat so that you do not damage the
coolant system.
Removing the door
1 Remove the decorative plugs from the top of the refrigerator, then
remove the four screws (two on the top and two on the back) holding
the top onto the refrigerator body.
2 Remove the top of the refrigerator.
3 Remove the screws holding the top hinge to your refrigerator, then
remove the hinge and the freezer door.
4 Remove the two screws holding the middle hinge to the refrigerator
body, then remove the hinge.
5 Pull the refrigerator door upwards and remove it from the refrigerator.
6 Tilt the refrigerator back or lay it on its back.
7 Unscrew the right and left leveling legs, then remove them.
