Insignia 4.3 Cubic Foot Compact Refrigerator
www.insigniaproducts.com
8 Unscrew the screws holding the bottom hinge on the refrigerator and
remove the hinge.
Reinstalling the doors
1 Reinstall the leveling leg you removed from the left side into the right
bottom of your refrigerator and the the leveling leg you removed from
the right side into the left bottom of your refrigerator.
2 Install the bottom hinge on the left bottom of your refrigerator using
the screws you previously removed. Tighten the screws.
3 Align the hole in the bottom left of the refrigerator door with the
bottom hinge pin, then install the door on the hinge pin.
4 Place the middle hinge pin into the left top of the refrigerator door,
then install the middle hinge on the left of the refrigerator with the
screws your previously removed.
5 Check the fit and alignment (vertical and horizontal) of the door and
make sure that it moves freely open and closed, then tighten the
screws holding the middle hinge.
