5 Remove the center hinge assembly from the center right side of your
refrigerator and the screw hole caps from the center left side of your
refrigerator, then remove the freezer door and set it aside.
6 Remove the bottom hinge assembly from the bottom right side of your
refrigerator and the adjustable foot from the bottom left side of your
refrigerator.
7 Install the bottom hinge assembly on the bottom left side of your refrigerator
and the adjustable foot on the bottom right side of your refrigerator.
Screw
hole caps
Center hinge
assembly
Screws
Bottom hinge
assembly
Adjustable foot
Adjustable
foot
Bottom hinge
assembly
