19
Top Control Dishwasher
www.insigniaproducts.com
Step 12: Securing the dishwasher to the countertop
• For countertops made of wood or materials that won’t be damaged by drilling, use Method 1.
• For countertops made of granite, marble, or other materials that could be damaged by drilling, use Method 2.
• If the gap between the control panel and the cabinet is less than 0.4 in. (10 mm), use method 2
Method 1
1 Insert the long top mounting clips into the slot.
2 Bend the brackets to secure them to the dishwasher tub.
3 Secure the dishwasher to the countertop through the holes in the brackets, using the screws provided.
Method 2
1 Remove the plastic tub caps from the inside of the dishwasher tub.
2 Drive a wood screw through the hole in the side of the dishwasher into the cabinet frame.
You’ll need:
Important: Drive the screws straight and flush. Protruding screw heads will scratch the top of the control panel and interfere with
the door closing.
Important: Drive the screws straight and flush. Protruding screw heads will scratch the side of the dishwasher. This method is for
attaching the dishwasher to the sides of the cabinet, and it should be done when the countertop is made of granite or other
breakable materials.
Phillips screwdriver
Wood screws (2)
(two for each method)
Top mounting clips (2)
