Insignia NS-LCD32 Service Manual

13
2. MST9883
MST9883 is a Triple Video A/D Converter with Clamps & Pixel Clock Synthesizer. The triple ADC
support 12 - 110 MHz Sampling Rate. It integrated 5-bit pixel clock phase adjustment for precise
sample timing control. Its Output support 4:2:2 Format Mode and it can Pin Compatible with
AD9883A.
Block diagram of MST9883 is flow:
