30" Square Fire Table - Black
STEP 5: Installing the door pane assembly
You n e e d :
1 Place the M4 x 5 mm screw (DD) through the hole in the right-center of the door, then screw the knob (EE) onto the
screw until tight.
2 Using four M6 x 25 mm bolts (CC), install the front door panel assembly (N) to the support posts on the front of the
table with the Phillips screwdriver (FF), then tighten the bolts.
FF Phillips screwdriver (1)
N Front door panel assembly
CC M6 × 25 mm bolt (4)
DD M4 × 5 mm bolt (1)
EE Knob (1)
