30" Square Fire Table - Black
STEP 7: Preparing and installing the burner assembly
You n e e d :
1 Turn the table assembly upright.
2 Using four STA4.2 x 9.5 mm screws (AA), attach the thermal baffle (C) to the bottom of the burner assembly (B) with the
Phillips screwdriver (FF), then tighten the screws.
3 Unscrew the switch button on the control panel of the burner assembly, then insert the AA battery (HH) into the switch
(- end first), then screw the switch button back into the control panel.
AA STA4.2 × 9.5 mm
screw (8)
HH AA battery (1)
B Burner assembly
C Thermal baffle
FF Phillips screwdriver (1)
