Insignia NS-R2001 AM/FM Stereo Receiver
www.insigniaproducts.com
Troubleshooting
If a problem occurs, run through the table below
before contacting Insignia.
If the problem persists, attempt to solve it by
switching the receiver off and on again. If this fails
to resolve the problem, contact Insignia. Under no
circumstances should you attempt to repair the
receiver yourself as this could void the warranty.
Specifications
Legal notices
FCC Part 15
This device complies with Part 15 of the FCC Rules. Operation of
this product is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply within the
limits for a class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
Category Problem Possible Solution
No power
• The AC power cord is
disconnected.
• Poor connection at AC
wall outlet or the outlet
is inactive.
• Connect the cord securely.
• Check the outlet using a lamp or
another appliance.
No sound
• The speaker cords are
disconnected.
• The volume is adjusted
too low.
•The MUTE button on the
remote control is pressed
to ON.
• Speakers are not
switched on.
• Incorrect selection of the
input source.
• Incorrect connections
between the
components.
• Check the speaker connections.
• Adjust the volume.
•Press the MUTE button to cancel
the muting effect.
• Turn on one or both speakers.
• Select the desired input source
correctly.
• Make connections correctly.
Stations cannot
be received
• No antenna is connected.
•The desired station
frequency is not tuned in.
• The antenna is in wrong
position.
• Connect an antenna.
• Tune in the desired station
frequency.
• Move the antenna and retry
tuning.
Preset stations
cannot be
received
• An incorrect station
frequency has been
memorized.
• The memorized stations
are cleared.
• Memorize the correct station
frequency.
• Memorize the stations again.
Poor FM
reception
• No antenna is connected.
• The antenna is not
positioned for the best
reception.
• Connect an antenna.
• Change the position of the
antenna.
Continuous
hissing noise
during FM
reception,
especially
when a stereo
broadcast is
received.
Weak signals.
• Change the position of the
antenna.
• Install an outdoor FM antenna.
Continuous or
intermittent
hissing noise
during AM
reception,
especially at
night.
Noise is caused by motors,
fluorescent lamps, or
lightning.
• Keep the receiver away from
noise sources.
• Install an outdoor AM antenna.
No recording
• Incorrect selection
between the
components.
• Incorrect operation of
each component for
playback and recording.
• Make connections correctly.
•Operate each component
correctly.
Remote control
unit does not
operate.
• Batteries are not loaded
or are exhausted.
• The remote sensor is
obstructed.
• Replace the batteries.
• Remove the obstacle.
Notes
• Design and specifications are subject to change
without notice.
• Weight and dimensions shown are
approximate.
• Specifications and external appearance may be
changed for the sake of improvement.
Amplifier
Power output, stereo mode, 8 Ω, THD 1%, 40 Hz~20 kHz: 2×100 W
Total harmonic distortion, 8 Ω, 100 W, 40 Hz~20 kHz: 0.04%
Intermodulation distortion, 60 Hz:7 kHz= 4:1 SMPTE, 8Ω, 100 W: 0.02 %
Input sensitivity, 47 kΩ, Phono (MM): 2.5 mV
Input sensitivity, 47 kΩ, Line (CD, AUX1, AUX2): 200 mV
Signal to noise ratio, IHF “A” weighted, Phono (MM): 70 dB
Signal to noise ratio, IHF “A” weighted, Line (CD, AUX1, AUX2): 95 dB
Frequency response Phono (MM), RIAA, 30 Hz~20 kHz: +/- 3 dB
Frequency response Line (CD, AUX1, AUX2), 20 Hz~100 kHz: +/- 3 dB
Output level AUX1, AUX2 OUT, 2.2 kΩ: 200 mV
Bass/Treble control, 100 Hz/10 kHz: ±10 dB
FM Tuner Tuning frequency range: 87.5~107.9 MHz
Usable sensitivity, THD 3%, S/N 30 dB: 15 dBf
50 dB quieting sensitivity, mono/stereo: 25.2 / 45.2 dBf
Signal to noise ratio, 65 dBf, mono/stereo: 68/65 dB
Total harmonic distortion, 65 dBf,1 kHz, mono/stereo: 0.5 / 0.8%
Frequency response, 20 Hz~14 kHz: +/- 3 dB
Stereo separation, 1 kHz: 40 dB
Capture ratio: 4 dB
IF rejection ratio: 80 dB
AM Tuner Tuning frequency range: 530~1710 kHz
Usable sensitivity: 800 μV/m
Signal to noise ratio: 40 dB
Selectivity: 25 dB
General Power supply: 120 V ~ 60 Hz
Power consumption: 2.5 A
Dimensions (W×H×D, including protruding parts):
17.32 × 4.87 × 13.12 inches (43.9 × 12.38 × 33.34 cm)
Weight (Net): 17.4 lbs (7.9 kg)
