9
29-Bottle Wine Cooler
www.insigniaproducts.com
Reversing the door
You need a 10 mm socket wrench and a Phillips screwdriver. Have someone
available to assist you in the process. Make sure that you keep all of the parts you
remove to reuse them later.
1 Make sure that your cooler is unplugged and empty.
2 Adjust the leveling feet to their highest positions.
3 Use a blade to remove the rivets.
4 Use a blade to remove the hinge cover, then use a Phillips screwdriver to
remove the hinge bolts.
5 Remove the upper hinge.
6 Remove the door from your cooler.
CAUTION: Do not lay your cooler completely flat as that could damage the coolant
system.
Axle sleeve
Hinge cover
Upper hinge
Hinge bolts
Axle sleeve
Rivets
