Service Manual 15
Commercial Disposers
Screw
Shield
Seal Assy.
Spacer Sleeve
O-ring
Slinger
Bearing Cone
& Cup
Cone Spacer
Bearing
Thrust Washer
Water & Oil Seal
Woodruff Key
Woodruff Key
Rotor & Shaft Assy.
Upper End Bell
Centrifugal Switch
(1 Phase only)
Lower Bearing
Figure 22. Upper End Bell and Rotor Assembly
