Service Manual 33
Commercial Disposers
SS-50 / SS-75 / SS-100 / SS-125
Small Capacity - 3 Phase UL & CSA
208-230/460V 60 Hz
Item Part No. Description Qty
1 11004 Mounting Flange 1
2 11016 Gasket, Mounting 1
3 11020A Upper Body Assy. 1
4 1491 Screw, 1/4-20 x 3/4" 6
5 11277 Pipe Plug 1
6 11006 Gasket, Shredder 1
7 12442ZZ Body and Cover Assy. 1
8 14664 Stationary Shredder 1
9 11260 Nut 1
10 12445 Washer 1
11 12142 Fiber Washer 1
12 12944ZZ Rotating Shredder 1
13 13722
Upper End Bell Assy
(includes items 14-22)
1
14 12936 Shield 1
15 1269 Screw, 8-18-1/2" 6
16 12934A Seal Assy. 1
17 12935 Spacer Sleeve 1
18 12860 O-ring 1
19 12319 Slinger 1
20 12610 Upper Bearing Assy. 1
21 12326 Water & Oil Seal 1
22 11322 Woodruff Key 3
23 13080
Bearing Seal Kit
(includes items 9-11 & 14-22)
1
24 11444 Lock Washer 3
25 3135 Screw, 1/4-20 x 1" 3
Item Part No. Description Qty
26 1470 Gasket, Tailpipe 1
27 8219 Tailpipe 1
28 1461 Flange, Tailpipe 1
29 1468 Screw, 1/4-20 x 1/2" 2
30
See Chart A Rotor & Shaft Assy. 1
31 12370ZZ Trim Band 1
32 1836A Screw, 8-32 x 1/2" 2
33 See Chart A Stator Assy. 1
34 12433EZZ Mounting Bracket Assy. 1
35 11448 Screw, 8-18 x 1/4" 4
36 12384 Bushing 1
37 See Chart A Overload Protector 1
38 12378 Clamp, Overload 1
39 8221 Screw, 8-32 x 1/2" 2
40 13396ZZ Terminal Box (includes 42) 1
41 12381 Screw, 8-32 x 1-1/4" 1
42 12383 Grommet, Overload 1
43 13709 Lower Bearing 1
44 13678 Pre-load Spring 1
45 13747 Lower End Frame 1
46 13676ZZ Fan 1
47 13677ZZ Retaining Ring 1
48 12490 Tube Spacer 3
49 11940A Thru Bolt 3
50 12396 Bottom Cover 1
51 2466A Screw, Ground 1
52 11757B Foot Tube Assy. (optional) 2
Chart A
Item Description Qty SS-50 SS-75 SS-100 SS-125
33 Rotor & Shaft Assy. 1 13674EZZ 13674GZZ 13274HZZ 13274JZZ
33 Stator Assy. 1 13714 13714A 13714B 13714C
37 Overload Protector 1 13422H 13422K 13422N 13422M
