Service Manual 35
Commercial Disposers
SS-150 / SS-200
Medium Capacity - 1 Phase UL & CSA
115/208-230V 60 Hz
Item Part No. Description Qty
1 11004 Mounting Flange 1
2 11016 Gasket, Mounting 1
3 See Chart A Upper Body Assy. 1
4 1491 Screw, 1/4-20 x 3/4" 6
5 11277 Pipe Plug 1
6 11007 Gasket, Shredder 1
7 12443ZZ Body and Cover Assy. 1
8 14663 Stationary Shredder 1
9 11260 Nut 1
10 12445 Washer 1
11 12142 Fiber Washer 1
12 12946ZZ Rotating Shredder 1
13 13723
Upper End Bell Assy
(includes items 14-22)
1
14 12936 Shield 1
15 1269 Screw, 8-18-1/2" 6
16 12934A Seal Assy. 1
17 12935 Spacer Sleeve 1
18 12860 O-ring 1
19 12319 Slinger 1
20 12610 Upper Bearing Assy. 1
21 12326 Water & Oil Seal 1
22 11322 Woodruff Key 3
23 13080
Bearing Seal Kit
(includes items 9-11 & 14-22)
1
24 11444 Lock Washer 6
25 11524 Screw, 1/4-20 x 1/2" 6
26 11459 Gasket, Tailpipe 1
27 13997 Flange, Tailpipe 1
Item Part No. Description Qty
28 13369 Screw, 1/4-20 x 3/4" 4
29 See Chart A
Rotor & Shaft Assy.
(includes item 30)
1
30 Not Repairable Centrifugal Actuator 1
31 8221 Screw, 8-32 x 1/2" 2
32 13707 Start Swtich 1
33 12426ZZ Trim Band 1
34 1836A Screw, 8-32 x 1/2" 2
35 See Chart A Stator Assy. 1
36 12433KZZ Mounting Bracket Assy. 1
37 11448 Screw, 8-18 x 1/4" 4
38 11868 Capacitor 1
39 8221 Screw, 8-32 x 1/2" 2
40 13396ZZ Terminal Box Assy. 1
41 12381 Screw, 8-32 x 1-1/4" 1
42 12383 Grommet, Overload 1
43 12378 Clamp, Overload 1
44 See Chart A Overload Protector 1
45 12384 Bushing 1
46 2466A Screw 1
47 13709 Lower Bearing 1
48 13678 Pre-load Spring 1
49 13710 Lower End Frame 1
50 13676ZZ Fan 1
51 13677ZZ Retaining Ring 1
52 12490 Spacer Tube 3
53 12432 Bottom Cover 1
54 12382A Thru Bolt 3
55 11757B Foot Tube Assy (optional) 2
Chart A
Item Description Qty SS-150
Short
SS-150
SS-200
Short
SS-200
3 Upper Body Assy 1 11024A 11024C 11024A 11024C
29 Rotor & Shaft Assy. with Centrifugal Actuator 1 13675ZZ 13675ZZ 13675AZZ 13675AZZ
35 Stator Assy. 1 13713D 13713D 13713E 13713E
44 Overload Protector 1 13422S 13422S 13422BA 13422BA
