Service Manual 37
Commercial Disposers
SS-150 / SS-200
Medium Capacity - 3 Phase UL & CSA
208-230/460V 60 Hz
Item Part No. Description Qty
1 11004 Mounting Flange 1
2 11016 Gasket, Mounting 1
3 See Chart A Upper Body Assy. 1
4 1491 Screw, 1/4-20 x 3/4" 6
5 11277 Pipe Plug 1
6 11007 Gasket, Shredder 1
7 12443ZZ Body and Cover Assy. 1
8 14663 Stationary Shredder 1
9 11260 Nut 1
10 12445 Washer 1
11 12142 Fiber Washer 1
12 12946ZZ Rotating Shredder 1
13 13723
Upper End Bell Assy
(includes items 14-22)
1
14 12936 Shield 1
15 1269 Screw, 8-18 x 1/2" 6
16 12934A Seal Assy. 1
17 12935 Spacer Sleeve 1
18 12860 O-ring 1
19 12319 Slinger 1
20 12610 Upper Bearing Assy. 1
21 12326 Water & Oil Seal 1
22 11322 Woodruff Key 3
23 13080
Bearing Seal Kit
(includes items 9-11 & 14-22)
1
Item Part No. Description Qty
24 11444 Lock Washer 6
25 11524 Screw, 1/4-20 x 1/2" 6
26 11459 Gasket, Tailpipe 1
27 13997 Flange, Tailpipe 1
28 13369 Screw, 1/4-20 x 3/4" 4
29 See Chart A Rotor & Shaft Assy. 1
30
12426ZZ Trim Band 1
31 1836A Screw, 8-32 x 1/2" 2
32 See Chart A Stator Assy. 1
33 12433EZZ Mounting Bracket Assy. 1
34 11448 Screw, 8-18 x 1/4" 4
35 See Chart A Overload Protector 1
36 12378 Clamp, Overload 1
37 8221 Screw, 8-32 x 1/2" 2
38 13396ZZ Terminal Box Assy. 1
39 12381 Screw, 8-32 x 1-1/4" 1
40 12383 Grommet, Overload 1
41 12384 Bushing 1
42 2466A Screw, Ground 1
43 13709 Lower Bearing 1
44 13678 Pre-load Spring 1
45 13747 Lower End Frame 1
46 13676ZZ Fan 4
47 13677ZZ Retaining Ring 1
48 12490 Tube Spacer. 3
49 12382A Thru Bolt 3
50 12432 Bottom Cover 1
51 11757B Foot Tube Assy. 2
Chart A
Item Description Qty SS-150
Short
SS-150
SS-200
Short
SS-200
3 Upper Body Assy 1 11024A 11024C 11024A 11024C
29 Rotor & Shaft Assy. 1 13675CZZ 13675CZZ 13275DZZ 13275DZZ
32 Stator Assy. 1 13714D 13714D 13714E 13714E
35 Overload Protector 1 13422M 13422M 13422P 13422P
