InSinkErator SS-50 - Page 42

Service Manual 39
Commercial Disposers
SS-300/SS-500/SS-750/SS-1000
large Capacity - 3 Phase UL & CSA
208-230/460V 60 Hz
Item Part No. Description Qty
1 11004 Mounting Flange 1
2 11016 Gasket, Mounting 1
3a
3b
See Chart A Upper Body Assy. 1
4 1491 Screw, 1/4-20 x 3/4" 6
5 11277 Pipe Plug 1
6 11008 Gasket, Shredder 1
7 11725ZZ Body and Cover Assy. 1
8 14662 Stationary Shredder 1
9 11255 Nut 1
10 11256 Washer 1
11 12143 Fiber Washer 1
12 13273ZZ Rotating Shredder 1
13 13320
Upper End Bell Assy
(includes items 14-22)
1
14 13266 Shield 1
15 1269 Screw, 8-18 x 1/2" 12
16 13260 Seal Assy. 1
17 13265 Spacer Sleeve 1
18 12859 O-ring 1
19 11729 Slinger 1
20 12638 Upper Bearing Assy. 1
21 11821 Thrust Washer 1
22 13398 Water & Oil Seal 1
23 11320 Woodruff Key 2
24 11322 Woodruff Key 1
25 13281A
Bearing Seal Kit
(includes items 9-11 & 14-22)
1
Item Part No. Description Qty
26 11444 Lock Washer 6
27 11524 Screw, 1/4-20 x 1/2” 6
28 11457 Gasket, Tailpipe 1
29 13998 Flange, Tailpipe 1
30 3130 Screw 4
31 See Chart A Rotor & Shaft Assy. 1
32 11721ZZ Trim Band 1
33 1836A Screw, 8-32 x 1/2” 2
34 See Chart A Stator Assy. 1
35 12357ZZ Insulation Tubing 1
36 12384 Bushing 1
37 See Chart A Bracket 1
38 11448 Screw, 8-18 x 1/4" 4
39 2466A Screw, Ground 1
40 See Chart A Overload Protector 1
41 12378 Clamp, Overload 1
42 01836A Screw 2
43 13396ZZ Terminal Box Assy. 1
44 12383 Grommet, Overload 1
45 12381 Screw 1
46 12415 Bearing 1
47 13678 Pre-Load Spring 1
48 11672 Lower End Frame 1
49 12395 Fan 1
50 12635 Retaining Ring 1
51 8039 Thru Bolt 4
52 11748 Bottom Cover 1
53 11757A Foot Tube Assy. 3
54 8221 Screw 3
Chart A
Item Description Qty SS-300 SS-500 SS-750 SS-1000
3a Upper Body Assy. (standard) 1 11232 11232 11232 11232
3b Upper Body Assy. (short) 1 11232B 11232B 11232B 11232B
31 Rotor & Shaft Assy. 1 13270ZZ 13270AZZ 13270ZZ 13270AZZ
34 Stator Assy. 1 13079 13079A 13079B 13079C
37 Bracket 1 12433AZZ 12433BZZ 12433BZZ 12433BZZ
40 Overload Protector 1 13422AW 13422B 13422AC 13422AC
