IPG Specifications
Factory Settings
Table 9. Inspire II IPG (Model 3024) Factory Settings
Parameter Value
General
Therapy On/Off Off
Usage 0
Start Delay 30 mins
Pause Time 15 mins
Therapy Duration 8 hrs
Stimulation
Amplitude 0 V
Rate 30 Hz
Pulse Width 90 μs
Amplitude Ramp Off
Electrode Configuration Outer (+) Center (–) Case (off)
Patient Control Off
Sensing
Exhalation Sensitivity | Threshold -1 | 0
Inhalation Sensitivity | Threshold -1 | 0
Refractory Hard | Soft 63% | 13%
Invert Signal Off
Max Stim Time 3 secs
