LCR-800 Series User Manual
v
EC Declaration of Conformity
We
GOOD WILL INSTRUMENT CO., LTD.
No. 7-1, Jhongsing Rd., Tucheng City, Taipei County 236, Taiwan
GOOD WILL INSTRUMENT (SUZHOU) CO., LTD.
No. 69 Lushan Road, Suzhou New District Jiangsu, China.
declare that the below mentioned products:
LCR-817/819/827/829/816/826/821
are herewith confirmed to comply with the requirements set out in the Council
Directive on the Approximation of the Law of Member States relating to
Electromagnetic Compatibility (89/336/EEC, 92/31/EEC, 93/68/EEC) and Low
Voltage Equipment Directive (73/23/EEC, 93/68/EEC).
For the evaluation regarding the Electromagnetic Compatibility and Low Voltage
Equipment Directive, the following standards were applied:
EN 61326-1: Electrical equipment for measurement, control and laboratory use ––
EMC requirements (1997+A1: 1998)
Conducted and Radiated Emissions
EN 55011 : 1998 Group I Class A
Electrostatic Discharge
IEC 61000-4-2: 1995
Current Harmonic
EN 61000-3-2: 2000
Radiated Immunity
IEC 61000-4-3: 1995
Voltage Fluctuation
EN 61000-3-3: 1995
Electrical Fast Transients
IEC 61000-4-4: 1995
————————————————
Surge Immunity
IEC 61000-4-5: 1995
————————————————
Conducted Susceptibility
IEC 61000-4-6: 1996
————————————————
Voltage Dips/ Interrupts
IEC 61000-4-11: 1994
Low Voltage Equipment Directive 73/23/EEC & amended by 93/68/EEC
Safety Requirements
IEC/EN 61010-1:2001
LCR-800 Series User Manual
1
1. INTRODUCTION
The precise LCR meter series are automatic, user programmable instruments
that provide high reliability and great precision for measuring a wide variety of
impedance parameters. The frequency range of LCR-819/829 covers from 12Hz
to 100kHz, LCR-817/827 from 12Hz to 10kHz, LCR-816/826 from 100Hz to
2kHz, and LCR-821 from 12Hz to 200kHz. The basic accuracy is 0.1% for LCR-
827/829/816/826, 0.05% for LCR-817/819/821. The measured results can be
displayed on the high quality LCD monitor with decimal points and units. The
measured result resolution is five full digits for Inductance (L), Capacitance (C),
Resistance (R) and absolute value of impedance (|Z|) [four full digits for
Dissipation factor (D), Quality factor (Q), R with C, R with L, 2 digits after
decimal dot for phase angle (θ)]. In the meantime, the LCD monitor is also shown
the control status and parameters of settings. The keypads are easy for menu
programming. The LCR Meters’ test fixture (option) is a method of convenient,
reliable, guarded 4-terminal/2 wires connection of radial and axial leaded
components to the LCR Meters. Test conditions can be stored and recalled from
internal memory that will reduce the setup time for measurement preparing.
