LCR-800 Series User Manual
6
(16). Numeral key—“2”
(17). Numeral key—“3”
(18). Numeral key—“5”
(19). Numeral key—“6”
(20). Numeral key—“9”
(21). Primary Display
This line can display the measured Inductance, Capacitance, or Resistance
(LCR-821 has Ζ).
(22). Secondary Display
This line can display the measured Quality Factor or Dissipation or ESR or
EPR (LCR-821 has Θ).
(23). Instrument status or indicates measurement results based on entered test
limits.
(24). Test conditions
(25). Input terminals
BNC connectors, connects to device under test (DUT).
Connectors of the LCR Meters
BIAS
Lforce (current, low)
＋
Lsense (potential low)
＋
Hsense (potential high)
－
Hforce (current, high)
－
LCR-800 Series User Manual
7
FRONT PANEL
