Instron 5984 - System Components and Interconnections

Chapter: Introduction
1-6 M10-16250-EN
System Components and Interconnections
Figure 1-3 on page 1-6 and Figure 1-4 on page 1-7 show you how each hardware
component is connected to make up the complete testing system.
Figure 1-3. 5982, 5984 and 5985 System Connections
GRN/YEL - Earth
BRN - Live
BLU - Neutral
Ground stud
Load cell
Load cell connection
Controller
Supplemental ground
cable
Computer interface
connection
Load cell cable
Mains power cable
Ethernet
crossover cable
System
ID label
