Load Frame Weights
Product Support: www.instron.com
Load Frame Weights
Table 2-9. 5988 and 5989 Dimensions
Dimension - mm (in) Letter
Frame
5988 5989
Crosshead thickness A 200 (7.9) 250 (9.8)
Minimum crosshead
position
B1 200 (7.9) 150 (5.9)
Maximum crosshead
position
B2 2050 (80.7) 2000 (78.7)
Table 2-10. Weights - Standard Configuration
Model Number
Weight
of Load Frame
Weight of Load Frame with
optional base extension
5982 784 kg (1725 lb) 875 kg (1925 lb)
5984 882kg (1940 lb) 973 kg (2140 lb)
5985 882 kg (1940 lb) 973 kg (2140 lb)
5988 2255 kg (4960lb) n/a
5989 2516 kg (5535lb) n/a
Table 2-11. Weights - Optional Configurations
Model Number Optional Configuration
Weight
of Load Frame
5982 Extra height 898 kg (1975 lb)
Extra wide 1011 kg (2225 lb)
Second test space 970 kg (2135 lb)
Extra height with second test space 1084 kg (2385 lb)
Extra height and extra wide 1102 kg (2425 lb)
