Ancillary Parts - Frames with a Second Test Space
For frames with a second test space, the following table lists the ancillary parts supplied in
addition to the standard parts kit.
10 MTS Ground cable A712-213-3 1 Used to connect the frame to a
suitable ground where the mains
power supply is not grounded
Locating ring type 2A T620-512 1 Locating ring for load cell- 82mm
diameter for M72 thread
Superbolt nut, M72 x 3P 52-2-74 1 To attach and preload load cell
Draw bar M72 x3 RH T620-479 1 Used with superbolt nut to attach load
cell to crosshead
Transducer cable assembly, 2.5 m A1735-1360-1 1 Load cell extension cable
Table 5-5. 5989 Ancillary Parts
Description
Part
Number Quantity Purpose
Table 5-6. Second Test Space Ancillary Parts
Description
Part
Number Quantity Purpose
Crosshead Clevis - Type D T1209-1138 1 Connects grips and fixtures to top of
crosshead
Screw, M10 x 30 201V55 6 To secure clevis type D
Locating ring T1335-1048 1 Load cell locating ring
Compression spring
3/4OD x 2 in length
66-4-5 1 Removes slack on lower grips with no
checknut
Retainer clip for 0.5 in diameter pin T1223-1053 1 Prevents the grip coupling pin from
sliding out during testing
Retaining pin, grip coupling T29-515 1 Secures the grip coupling
